Timber floor fitting guide
Timber support, electric underfloor heating, bedding, wall junctions and drain care.
Technical support
Fitting guides & technical downloads
Installation instructions, floor details and drain drawings for Resin Rock products.
Fitting guides
Choose your floor type and read the relevant trap drawing before starting.
Concrete floor fitting guide
Existing floor recesses, new screed shuttering, waste connections, fitting and drain care.
All guides in one file
10 guides covering timber and concrete floors, floor build ups, drains, wall hung sinks and maintenance. PDF · 34 pages. Tray specifications are available separately below.
Floor construction
Timber floor build up
Labelled floor section and original 1200 × 900 mm CAD drawing.
Concrete floor build up
Floor layers, flush tray junction, trap support and shuttering for new screed.
Drains & traps
Match the model code to the trap supplied with your tray.
Wall hung sink installation
Wall hung sink installation
Installation guide for heavy duty brackets and concealed bolt kits, with microcement finishing options and final checks.
Care & maintenance
Drain & trap maintenance
Cover removal, routine cleaning and photographs of removable trap components.
Need help with an installation?
Send us your tray size, floor type and a photograph or drawing of the proposed build up so we can advise on your installation.
Tray specifications
Round drain trays
Dimensions, construction details and drainage information for round drain trays.
Choose a size to view its dimensions and drain position. All sizes are in millimetres.
Product specifications
- Tray thickness
Approximately 30 mm.
- Drain type
160mm Round drain with microcement ready cover.
- Surface
Factory textured and pre primed for microcement.
- Included
Resin Rock tray, McAlpine waste and trap kit, Microcement ready drain insert
- Waste flow rate
34 litres per minute
- Alterative Waste
2" High flow waste available ST90-HPB
- Bespoke options
Custom sizes, shapes and drainage positions available on request.
Sizes and drawings
700 × 700 mmView drawing
700 × 1000 mmView drawing
700 × 1200 mmView drawing
800 × 800 mmView drawing
800 × 1000 mmView drawing
800 × 1200 mmView drawing
800 × 1400 mmView drawing
800 × 1500 mmView drawing
900 × 900 mmView drawing
900 × 1000 mmView drawing
900 × 1200 mmView drawing
900 × 1400 mmView drawing
900 × 1500 mmView drawing
1000 × 1000 mmView drawing
1200 × 1200 mmView drawing
Tray specifications
Linear drain trays: short edge
Dimensions, construction details and drainage information for 550 mm linear drain trays with the drain on the short edge.
Choose a size to view its dimensions and drain position. All sizes are in millimetres.
Product specifications
- Tray thickness
Approximately 30 mm.
- Drain type
550 mm linear drain along the short edge.
- Surface
Factory textured and pre primed for microcement.
- Included
Resin Rock tray, McAlpine waste and trap kit, Microcement ready drain insert
- Waste flow rate
54 litres per minute.
- Low profile waste
Low profile option available. STW4-65
- Bespoke options
Custom sizes, shapes and drainage positions available on request.
Sizes and drawings
700 × 700 mmView drawing
700 × 1200 mmView drawing
800 × 800 mmView drawing
800 × 1000 mmView drawing
800 × 1200 mmView drawing
800 × 1300 mmView drawing
800 × 1400 mmView drawing
800 × 1500 mmView drawing
900 × 900 mmView drawing
900 × 1000 mmView drawing
900 × 1200 mmView drawing
900 × 1300 mmView drawing
900 × 1400 mmView drawing
900 × 1500 mmView drawing
900 × 1600 mmView drawing
1000 × 1000 mmView drawing
1000 × 1200 mmView drawing
Tray specifications
Linear drain trays: long edge
Dimensions, construction details and drainage information for 550 mm linear drain trays with the drain on the long edge.
Choose a size to view its dimensions and drain position. All sizes are in millimetres.
Product specifications
- Tray thickness
Approximately 30 mm.
- Drain type
550 mm linear drain along the long edge.
- Surface
Factory textured and pre primed for microcement.
- Waste kit
McAlpine waste and trap kit, drain insert and required fittings included.
- Waste flow rate
54 litres per minute.
- Low profile waste
Low profile option available. STW4-65
- Bespoke options
Custom sizes, shapes and drainage positions available on request.
